Various lysates were subjected to SDS PAGE followed by western blot with 66149-1-Ig (TIMM44 antibody) at dilution of 1:10000 incubated at room temperature for 1.5 hours. The membrane was stripped and reblotted with HRP-conjugated GAPDH Monoclonal antibody (HRP-60004) as loading control. This data was developed using the same antibody clone with 66149-1-PBS in a different storage buffer formulation.

Immunohistochemical analysis of paraffin-embedded human liver tissue slide using 66149-1-Ig (TIMM44 antibody) at dilution of 1:500 (under 10x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0). This data was developed using the same antibody clone with 66149-1-PBS in a different storage buffer formulation.

WB result of TIMM44 antibody (66149-1-Ig; 1:8000; incubated at room temperature for 1.5 hours) with sh-Control and sh-TIMM44 transfected HeLa cells. This data was developed using the same antibody clone with 66149-1-PBS in a different storage buffer formulation.

Immunofluorescent analysis of (4% PFA) fixed HepG2 cells using TIMM44 antibody (66149-1-Ig, Clone: 4G7D4 ) at dilution of 1:400 and CoraLite®594-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L). This data was developed using the same antibody clone with 66149-1-PBS in a different storage buffer formulation.
