ATG7 Monoclonal antibody, PBS Only

LNCaP cells were subjected to SDS PAGE followed by western blot with 67341-1-Ig (ATG7 antibody) at dilution of 1:10000 incubated at room temperature for 1.5 hours. The membrane was stripped and reblotted with HRP-conjugated Alpha Tubulin Monoclonal antibody (HRP-66031) as loading control. This data was developed using the same antibody clone with 67341-1-PBS in a different storage buffer formulation.

Immunohistochemical analysis of paraffin-embedded human cervical cancer tissue slide using 67341-1-Ig (ATG7 antibody) at dilution of 1:1000 (under 10x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0). This data was developed using the same antibody clone with 67341-1-PBS in a different storage buffer formulation.

Immunofluorescent analysis of (-20°C Ethanol) fixed HeLa cells using 67341-1-Ig (ATG7 antibody) at dilution of 1:100 and CoraLite488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L). This data was developed using the same antibody clone with 67341-1-PBS in a different storage buffer formulation.

WB result of ATG7 antibody (67341-1-Ig; 1:4000; incubated at room temperature for 1.5 hours) with sh-Control and sh-ATG7 transfected HepG2 cells. This data was developed using the same antibody clone with 67341-1-PBS in a different storage buffer formulation.

1X10^6 HeLa cells were intracellularly stained with 0.5 ug Anti-Human ATG7 (67341-1-Ig, Clone:2B5A10) and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L) at dilution 1:1000 (red), or 0.5 ug Mouse IgG2a Isotype Control (66360-2-Ig, Clone: K11A1B2A2) (blue). Cells were fixed with 4% PFA and permeabilized with Flow Cytometry Perm Buffer (PF00011-C). This data was developed using the same antibody clone with 67341-1-PBS in a different storage buffer formulation.
