band 3/ AE1 Monoclonal antibody

band 3/ AE1 Monoclonal Antibody for IF-P, IHC, ELISA

Host / Isotype

Mouse / IgG1

Reactivity

Human

Applications

IF-P, IHC, ELISA

Conjugate

Unconjugated

CloneNo.

1E5C1

Cat No : 66984-1-Ig

Print datasheet

Synonyms

AE 1, AE1, Anion exchange protein 1, Anion exchanger 1, Band 3 anion transport protein, band 3/ AE1, BND3, CD233, DI, EMPB3, EPB3, FR, RTA1A, SLC4A1, SW, WD, WD1, WR

验证数据展示

  • IHC staining of human placenta using 66984-1-Ig

    IHC staining of human placenta using 66984-1-Ig

    Immunohistochemical analysis of paraffin-embedded human placenta tissue slide using 66984-1-Ig (band 3/ AE1 antibody) at dilution of 1:10000 (under 40x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

    Ready-to-use IHC kits available with Band 3/AE1 antibody included
  • IF Staining of human placenta using 66984-1-Ig

    IF Staining of human placenta using 66984-1-Ig

    Immunofluorescent analysis of (4% PFA) fixed human placenta tissue using band 3/ AE1 antibody (66984-1-Ig, Clone: 1E5C1 ) at dilution of 1:400 and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L).

经过测试的应用

Positive IHC detected inhuman placenta tissue
Note: suggested antigen retrieval with TE buffer pH 9.0; (*) Alternatively, antigen retrieval may be performed with citrate buffer pH 6.0
Positive IF detected inhuman placenta tissue
Planning an IHC experiment? We recommend our IHCeasy Band 3/AE1 Ready-To-Use IHC Kit. Band 3/AE1 primary antibody included.
Planning an IF experiment? We recommend our CoraLite® Plus 488 and CoraLite®594 conjugated versions of this antibody.

推荐稀释比

ApplicationDilution
Immunohistochemistry (IHC)IHC : 1:5000-1:20000
Immunofluorescence (IF)IF : 1:200-1:800
It is recommended that this reagent should be titrated in each testing system to obtain optimal results.
Sample-dependent, Check data in validation data gallery.

产品信息

66984-1-Ig targets band 3/ AE1 in IF, IHC, ELISA applications and shows reactivity with Human samples.

Tested Applications IF-P, IHC, ELISA
Tested Reactivity Human
Immunogen band 3/ AE1 fusion protein Ag28058 种属同源性预测
Host / Isotype Mouse / IgG1
Class Monoclonal
Type Antibody
Full Name solute carrier family 4, anion exchanger, member 1 (erythrocyte membrane protein band 3, Diego blood group)
Synonyms AE 1, AE1, Anion exchange protein 1, Anion exchanger 1, Band 3 anion transport protein, band 3/ AE1, BND3, CD233, DI, EMPB3, EPB3, FR, RTA1A, SLC4A1, SW, WD, WD1, WR
Calculated Molecular Weight 911 aa, 102 kDa
GenBank Accession NumberBC101570
Gene Symbol SLC4A1
Gene ID (NCBI) 6521
RRIDAB_2918479
Conjugate Unconjugated
Form Liquid
Purification MethodProtein A purification
UNIPROT IDP02730
Storage Buffer PBS with 0.1% sodium azide and 50% glycerol pH 7.3.
Storage ConditionsStore at -20°C. Stable for one year after shipment. Aliquoting is unnecessary for -20oC storage.

背景介绍

Anion exchanger 1 (AE1), also known as band 3, is a 95-100 kDa transmembrane glycoprotein which is abundantly expressed in erythrocyte plasma membrane and mediates the electroneutral exchange of Cl- and HCO3-. It contains a 52-55 kDa C-terminal membrane crossing domain and a 43 kDa N-terminal cytoplasmic domain. Degradation of band 3 protein occurred during erythrocyte aging. The oxidative stress can also activate the proteolysis of band 3 through caspases. This antibody is expected to recognize the intact band 3 (95-100 kDa) and various degradation products (38-60 kDa). (PMID: 22890269, 29240292, 28130418)

实验方案

Product Specific Protocols
IHC protocol for band 3/ AE1 antibody 66984-1-IgDownload protocol
IF protocol for band 3/ AE1 antibody 66984-1-IgDownload protocol
Standard Protocols
Click here to view our Standard Protocols
